Modular Site Building Container Office
FoToon Housing Serviceyog Tuam Tshoj Prefab Thawv Tsev Chaw tsim khoom thiab xa tawm kev pabcuam. Peb lub Hoobkas tsuas yog tsim Prefab Container House, Flat Pack Container Office, Prefab School, Prefab Hotel, Container Toilet, thiab lwm yam. Kev Pabcuam Rau Prefab Vaj Tsev yog muaj los ntawm peb.
Hais txog cov kev pabcuam xa tawm, peb muaj ib pab neeg los saib xyuas cov neeg siv khoom Sourcing Suav Cov Khoom - rau tam sim no nws tsuas yog npog Steel Raw cov ntaub ntawv & tshuaj Chemical Cheebtsam, Tshuaj xyuas ntau lawm & Loading.
FoToon Housing Service muab cov thawv zoo:
Peb lub thawv chaw ua haujlwm tau tsim los siv los ua thaj chaw ua haujlwm ib ntus rau cov neeg ua haujlwm, tsis hais txog qhov chaw tsim kho.
Peb lub thawv prefabricated tuaj yeem dismantled nyob rau hauv lub ru tsev seem, pem teb puag seem, kab, phab ntsa panels nrog lub qhov rooj thiab qhov rais. Feem ntau, qhov loj tshaj plaws yog 20ft Prefab Thawv Tsev / Chaw Ua Haujlwm nrog 6.058 x2.438 x 2.896m. Cov thawv ntim hauv chaw ua haujlwm tuaj yeem hloov kho thiab qhov loj me kom suav nrog cov kev xaiv hauv qab no: cua txias, rooj tog zaum, khoos phis tawj network thiab xov tooj, tsev automation, guardrail (guardrail), pem teb siab. Prefab Office ntim (chaw ua hauj lwm chaw ua hauj lwm) yog xa raws li ib tug ca pob teeb disassembled los yog me me ntim thiab tag nrho assembled & thauj mus rau hauv lub thawv shipping.
Mineral wool uas yog siv feem ntau rau kev rwb thaiv tsev hauv cov qauv tuaj yeem rov ua dua
Cov qauv ntawm lub cabin yog tsim los ntawm cov hlau thiab thaum tus neeg siv tsis tau siv cov qauv ntxiv, cov hlau tuaj yeem rov ua dua tshiab.
Modular containers loading daws:
Rau tus qauv 20ft Thawv Chaw Ua Haujlwm, nws nruab nrog ib lub qhov rooj thiab ob lub qhov rais, tag nrho cov khoom siv hluav taws xob, 5 units thauj khoom rau hauv 1x40ft HQ shipping thawv lossis 4 units tiaj tus pob li 20ft SOC & ncaj qha thauj mus rau hauv lub nkoj.
Modular ntim cov ntawv thov:
Peb cov chaw ua haujlwm ntim tuaj yeem koom ua ke (sib dhos lossis stacked) los tsim cov tsev loj prefabricated modular. Cov thawv ntim khoom tuaj yeem nyob hauv Kev Tsim Kho Chaw, Mining Camp cheeb tsam, Roj Tshawb Nrhiav Chaw Haujlwm rau Chaw Ua Haujlwm Ib ntus. Thiab cov thawv no tuaj yeem thauj mus rau lwm qhov chaw thaum ib qhov project tiav thiab thauj mus rau lub tsheb thauj mus los.
Tsim kom nthuav dav rau cog chaw ua haujlwm nyob qhov twg yooj yim. Lub modular phab ntsa system koom nrog kev sib koom ua ke ntawm cov chaw ua haujlwm sab hauv ib leeg nrog xaiv 100 hli phab ntsa panels. Lub tsev modular kuj tseem txhawb nqa tag nrho cov kev yooj yim ntawm cov chaw hauv pem teb. Txhua module yog sib dhos ua ntej xa khoom. Cov chaw ua haujlwm txawb no tseem muaj qhov rooj thiab qhov rais, ua kom huv thiab tiaj tus. Zuag qhia tag nrho cov txheej txheem kev tsim kho yog guaranteed ceev thiab zoo.
Yuav kom tsim tau sai dua rau lub Thawv Chaw Ua Haujlwm loj, peb xav kom cov neeg siv khoom sib txuas 20ft Thawv hauv kab, 16ft thawv raws li txoj kev hauv tsev thiab lwm txoj kab txuas nrog 20ft Thawv. Txhawm rau kom cov hnub ci nkag mus rau hauv chav tsev, peb lub Hoobkas muaj peev xwm muab cov iav phab ntsa rau ntau lub teeb. Qhov ntau thiab tsawg ntawm Windows tuaj yeem hloov kho hauv lub Hoobkas thiab sib sau ua ke rau hauv phab ntsa panels.
Modular Container Office specification hauv cov ntsiab lus:
| 1 | Phab ntsa vaj huam sib luag | Phab ntsa vaj huam sib luag | 60 hli thickness EPS sandwich vaj huam sib luag nrog 0.5mm thickness dawb-grey xim hlau daim tawv nqaij, 16kg / m3 ntom rwb thaiv tsev |
| Sab hauv phab ntsa vaj huam sib luag | TSIS MUAJ | ||
| 2 | Rooj | Sab hauv sab saum toj board | 50 hli thickness EPS sandwich vaj huam sib luag nrog 0.5mm thickness dawb-grey xim hlau daim tawv nqaij, 16kg / m3 ceev rwb thaiv tsev |
| Insulation ib feem ntawm sab saum toj | 75mm Pob zeb Wool rwb thaiv tsev | ||
| Sab nrauv sab saum toj board | 0.5 hli thickness xim hlau | ||
| Ru tsev kho dej | 50mm Dia PVC yeeb nkab rau ru tsev dej system. | ||
| STEEL FRAME | |||
| 3 | Hlau ncej | Kem | 3.0mm Galvanized steel dabtsi yog khoov + Epoxy zinc nplua nuj xim tiav |
| Pem teb puag lub ntsiab nqaj | 3.0mm steel dabtsi yog khoov lub ntsiab nqaj + Epoxy zinc nplua nuj xim tiav | ||
| Pem teb puag ncig beam | 80x40mm Galvanized steel plaub lub raj | ||
| Lub ntsiab ncej | 3.0mm steel dabtsi yog khoov lub ntsiab nqaj + pleev xim tiav | ||
| Ru tsev theem nrab beam | 40x40mm Galvanized Steel Rectangular Tube | ||
| Rooj haum | tshwj xeeb rau lub tsev thawv, ISO tus qauv | ||
| Skirting kab rau decorate phab ntsa edged | PVC skirting kab | ||
| PIB | |||
| 4 | Pem teb | Pem teb puag | 18 hli Fiber cement board |
| Pem teb tiav | 1.8mm PVC pem teb | ||
| Pem teb rwb thaiv tsev | 75mm Pob zeb Wool rwb thaiv tsev | ||
| 5 | Qhov Rooj & Qhov rai | Qhov rooj | 840x2040mm dawb xim ruaj ntseg qhov rooj nrog stainless hlau xauv; Aluminium Alloy ob chav glazed iav zawv zawg qhov rooj nrog xauv. |
| Qhov rai | 900x1200mm dawb xim Aluminium Alloy zawv zawg qhov rais nrog ob chav glazed iav 5/9/5mm & ya npo. | ||
| Qhov rai qhwv nplooj | aluminium alloy | ||
| KEV PAB CUAM | |||
| 6 | Khoom siv | Khoom siv | bolt, ntsia hlau, iav kua nplaum, txuas ib feem, cov cuab yeej yooj yim rau kev sib dhos |
| Cov khoom siv hluav taws xob | hluav taws xob faib board, ib theem Circuit Court breaker, sockets, keyboards, teeb, hlau nyob rau hauv New Zealand lub teb chaws tus qauv | ||
| Cov chaw | TSIS MUAJ | ||
Modular Site Building Container Office raw khoom duab:
Container Office Floor base section
Container Office phab ntsa vaj huam sib luag
Container Office customized kab
Container Office iav qhov rooj
Thawv Office pem teb
Container Office flat pack box
Container Office SOC flat pack
Pls hu raustevexue@ftprefabhouse.comYog xav paub ntxiv yog tias koj xav tau lub Thawv Chaw Ua Haujlwm Ib ntus, Chaw Ua Haujlwm Pabcuam Thawv Chaw Ua Haujlwm, Thawv Ablution Blocks, Prefab Container School Buildings.
